G75B

G75B

Easy to adjust and maintain, Hunter’s G75B golf and large turf rotor is also the ideal choice for the customer on a budget. The B Series rotors provide all the standard features you want for mid-distance coverage including a time-tested gear drive, convenient through-the-top servicing, and a sturdy, impact-resistant flanged body. Plus Hunter’s PressurePort™ nozzling system reduces velocity and pressure to the secondary nozzles while increasing droplet size. The result is they deliver uniform distribution every time.

Operating specifications

Full/Part circle 50° to 360°. Radius: 14.3 to 21.6 m
Flow Rate: 1.75 to 7.34 m3/hr
Operating pressure range: 2.8 to 6.9 bar; 275 to 689 kPa
Precipitation rates: 12 mm/hr approx
All B Series rotors are pressure rated at 10 bars; 1,000kPa

Warranty period: 3 years
