| Code | Size | Weight | Bolts | Packing |
|---|---|---|---|---|
| No | mm x in | g | pcs | |
| 550B02001 | 20X1/2 | 63.9 | 2 | 400 |
| 550B02501 | 25X1/2 | 63.9 | 2 | 300 |
| 550B02502 | 25X3/4 | 61.4 | 2 | 300 |
| 550B03201 | 32X1/2 | 74.5 | 2 | 270 |
| 550b03203 | 32X3/4 | 72 | 2 | 270 |
| 550B03202 | 32X1 | 2 | 250 | |
| 550B04001 | 40X1/2 | 107 | 2 | 180 |
| 550B04002 | 40X3/4 | 104 | 2 | 180 |
| 550B04003 | 40X1 | 109 | 2 | 150 |
| 550B05001 | 50X1/2 | 164 | 2 | 120 |
| 550B05002 | 50X3/4 | 164 | 2 | 120 |
| 550B05003 | 50X1 | 166 | 2 | 120 |
| 550B06301 | 63X1/2 | 174 | 2 | 80 |
| 550B06302 | 63X3/4 | 175 | 2 | 80 |
| 550B06303 | 63X1 | 175 | 2 | 80 |
| 550B45001 | 50X1/2 | 205 | 4 | 100 |
| 550B45002 | 50X3/4 | 214 | 4 | 100 |
| 550B45003 | 50X1 | 217 | 4 | 100 |
| 550B45004 | 50X11/4 | 230 | 4 | 100 |
| 550B46301 | 63X1/2 | 239 | 4 | 80 |
| 550B46302 | 63X3/4 | 235 | 4 | 80 |
| 550B46303 | 63X1 | 236 | 4 | 80 |
| 550B46304 | 63X11/4 | 226 | 4 | 70 |
| 550B46305 | 63X11/2 | 247 | 4 | 70 |
| 550B07501 | 75X1/2 | 266 | 4 | 65 |
| 550B07502 | 75X3/4 | 276 | 4 | 65 |
| 550B07503 | 75X1 | 269 | 4 | 65 |
| 550B07504 | 75X11/4 | 289 | 4 | 60 |
| 550B07505 | 75X11/2 | 308 | 4 | 60 |
| 550B07506 | 75X2 | 322 | 4 | 60 |
| 550B09001 | 90X1/2 | 354 | 4 | 45 |
| 550B09002 | 90X3/4 | 345 | 4 | 40 |
| 550B09003 | 90X1 | 346 | 4 | 40 |
| 550B09004 | 90X11/4 | 349 | 4 | 40 |
| 550B09005 | 90X11/2 | 369 | 4 | 35 |
| 550B09006 | 90X2 | 372 | 4 | 35 |
| 550B11001 | 110X1/2 | 509 | 4 | 30 |
| 550B11002 | 110X3/4 | 503 | 4 | 30 |
| 550B11003 | 110X1 | 507 | 4 | 30 |
| 550B11004 | 110X11/4 | 517 | 4 | 30 |
| 550B11005 | 110X11/2 | 555 | 4 | 30 |
| 550B11006 | 110X2 | 531 | 4 | 25 |
| 550B11008 | 110X3 | 588 | 4 | 24 |
| 550B12502 | 125X3/4 | 512 | 4 | 30 |
| 550B12503 | 125X1 | 511 | 4 | 30 |
| 550B12504 | 125X11/4 | 518 | 4 | 30 |
| 550B12505 | 125X11/2 | 518 | 4 | 30 |
| 550B12506 | 125X2 | 528 | 4 | 30 |
| 550B12508 | 125X3 | 847 | 6 | 30 |
| 550B14002 | 140X3/4 | 753 | 6 | 24 |
| 550B14003 | 140X1 | 760 | 6 | 24 |
| 550B14004 | 140X1 1/4 | 795 | 6 | 24 |
| 550B14005 | 140X11/2 | 795 | 6 | 24 |
| 550B14006 | 140X2 | 829 | 6 | 24 |
| 550B16002 | 160X3/4 | 796 | 6 | 24 |
| 550B16003 | 160X1 | 792 | 6 | 24 |
| 550B16004 | 160X11/4 | 802 | 6 | 24 |
| 550B16005 | 160X11/2 | 835 | 6 | 24 |
| 550B16006 | 160X2 | 807 | 6 | 24 |
| 550B16008 | 160X3 | 1107 | 6 | 16 |
| 550B16009 | 160X4 | 1122 | 6 | 16 |
| 550B20001 | 200X1/2 | 1793 | 6 | 10 |
| 550B20002 | 200X3/4 | 1795 | 6 | 10 |
| 550B20003 | 200X1 | 1781 | 6 | 10 |
| 550B20004 | 200X11/4 | 1773 | 6 | 10 |
| 550B20005 | 200X11/2 | 1767 | 6 | 10 |
| 550B20006 | 200X2 | 1790 | 6 | 10 |
| 550B20008 | 200X3 | 1816 | 6 | 10 |
| 550B20009 | 200X4 | 1803 | 6 | 10 |
| 550B22506 | 225X2 | 2260 | 6 | 6 |
| 550B22508 | 225X3 | 2260 | 6 | 6 |
| 550B22509 | 225X4 | 2260 | 6 | 6 |
| 550B25006 | 250X2 | 2790 | 6 | 4 |
| 550B25008 | 250X3 | 2790 | 6 | 4 |
| 550B25009 | 250X4 | 2790 | 6 | 4 |
| 550B31506 | 315X2 | 4150 | 6 | 3 |
| 550B31508 | 315X3 | 4150 | 6 | 3 |
| 550B31509 | 315X4 | 4150 | 6 | 3 |
